Angle of viewFront Camera: H-106°, D-139°, V-77°Cabin Camera: H-125°, D-150°, V-65.4°

Image SensorFront Camera: 1/2.8

LensFront Camera: 3.0 mm,Cabin Camera: 2.82 mm

Max.ApertureFront Camera: F1.5,Cabin Camera: F2.0

CompressionFront Camera: H.265,Cabin Camera: H.265

ResolutionFront Camera: 8MCabin Camera: 2MP (1920 x 1080p)

Night Vision4 x 940nm IR LEDs

Screen typeIPS (In-Plane Switching)

Screen size2.45

Screen Resolution480 x 272

Video FormatMP4

Video resolution8MP (3840 x 2160p)@25fps +2MP (1920 x 1080p)@25fps +2MP (1920× 1080p)@25fps

Smart FeaturesGPS Logging, Voice Prompt, Time-Lapse , G-sensor, Parking Mode, Collision Detecon, WDR

Record TypeAudio Recording, Regular Recording, Parking mode, Time-Lapse

Parking ModeSupport (Type C Hardwire Kit)

MicrophoneSupport

SpeakerSupport

ConnectivityAP Mode (Dashcam creates its own Wi-Fi hotspot/ Direct Wi-Fi to phone)

SD Card1TB Max (Class 10 U3 Category)

Mobile AppCarKam (Available for iOS and Android Devices)

Photo FormatJPG

Super CapacitorSupport

Housing TypePC + ABS

Power SourceType C 5V/2.4A

Operating Temperature-10℃~60C

Storage Temperature-20°℃~70C

Dimensions (W × D × H)108.5 mm x 45 mm x 45.5 mm (including lens)

CertificatesISO 9001: 2015, ISO 14001 : 2015, ISO 45001 : 2018, ISO 20000-1 : 2018, ISO 50001:2018, CE, FCC and RoHS, BIS

Input voltage12Vdc

Working voltage Range12Vdc-30Vdc

Input CurrentUPTO 1.6A Max.@12Vdc Input & at 2.4amp. max load

No Load Input CurrentUPTO 06mA Max.@12Vdc Input & at No load output

Output voltage5.0V

Port TypeC Type

Type C Port (Voltage and current)5.0V/0A (4.70V to 5.35V) / 5.0V/2.4A (4.70V to 5.35V)

Type C A8 PIN (Voltage and current)5.0V/0A (4.80V to 5.20V ) Type C port no load

C Port Output current Limit2.9A (2.6A to 3.2A)

Ripple and Noise50mVp-p

EfficiencyMin 75% at full load

Short circuit protectionInput power shall decrease when the output short, the power supply shall no damage, and shall be self recovery when the fault condition is removed.

Over Current ProtectionOutput shall hiccup/ no load when the over current applied to the output, and shall be self-recovery when the fault condition is removed.

Low voltageBattery voltage is lower than 16V, it is judged as a car, battery voltage is lower than 11.8V±0.2V for 3 seconds, the voltage reduction line will automatically turn off the out-put.

High voltageBattery voltage is higher than 16V, it is judged as a large vehicle, battery voltage is low-er than 23.6V±0.4V for 3 seconds, the voltage reduction line will automatically turn off the output

Low voltage recovery conditionsBattery voltage is higher than the low voltage set value & ACC IN is input before it can be

Low voltage invalidBattery voltage is higher than the low voltage set value & ACC IN is input before it can be

Working Ambient Temperature-20〜 +70°C

Working Relative humidity20% ~ 90%

Storage Ambient Temperature-20°C ~ +80°C (-40°C ~ +85°C , @72H)

Storage Relative humidity5% ~ 95%

Aging testAged for 2 hours at full load in a normal temperature environment

Lightning strikeInput DC40V lightning strike

Drop TestFreely from 1.0m height onto the surface which is consisted of wooden floor, 6 sides, 1times each side

Input line (0.5m) CableDC Power V+(RED) & V-(BLACK) , ACC power (YELLOW)

Output Cable TypeType C cable

Output Type Cable Distance2.8 meters

Output Type C cable (2.8 meters)DC Power for Type C V+(RED) & V-(BLACK) , ACC for Type C A8 Pin ( YELLOW)
